3064195

STB Series: Self-Checking Touch Button w/Yellow F.C., Input: 20-30 V ac or dc, Upper Housing: Polycarbonate, Outputs: Two Independ

Manufacturer's No: STBVR81LQ6     Manufacturer: Turck Banner
STB Series: Self-Checking Touch Button w/Yellow F.C., Input: 20-30 V ac or dc, Upper Housing: Polycarbonate, Outputs: Two Independent and Complementary Relays, M12 Integral QD

Availability On Request

£209.11
  • Photoelectric sensor for two-hand control system
  • Operating voltage: 20-30 VAC / 20-30 VDC
  • M12 × 1 male, 5-pin connection
  • Protection class IP66
  • Relay output: 125 VDC / 150 VAC, 1A DC / AC 0.4A max
  • Safety category 4 according to EN ISO 13849-1
  • SIL 3 according to IEC 61508 and IEC 62061
  • Ergonomically shaped with upper housing part made of Lexan
  • Pre-assembled protective cover included


Product

Manufacturer Material ID -
STBVR81LQ6
Net Weight -
0.22kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
CN
UNSPSC -
39122216
Turck Banner

Availability On Request

£209.11
