2CPX010450R9999

TZ101 Flange, 147 mm x 223 mm x 20 mm

Manufacturer's No: TZ101     Manufacturer: ABB
TZ101 Flange, 147 mm x 223 mm x 20 mm

Availability Back Order

£30.90
  • TZ101 Flange
  • Dimensions: 147 mm x 223 mm x 20 mm
  • Material: Plastic membrane with integrated gasket
  • Tool-less mounting using locking gear
  • Suitable for line diameters: 2 x 6 - 32.5 mm, 2 x 6 - 25 mm, 4 x 6 - 19 mm, 10 x 6 - 15 mm, 2 x 6 - 12 mm, 31 x 6 - 11 mm, 1 x 6 - 7 mm
  • Compatible with TwinLine-G (SZ) meter cabinets, TwinLine wall, and standing cabinets
  • Factory-included for top flange openings in TwinLine-G (SZ)


Product

Manufacturer Material ID -
TZ101
Net Weight -
0.18kg

Additional Product Information

Commodity Code -
39174000
Country of Origin -
DE
UNSPSC -
31261502

Technical Specification

Degree of protection (NEMA) -
UN
Depth -
20 Millimetre
Thread type -
None
Suitable for nominal thread metric/PG -
0
Height -
147 Millimetre
Material -
Plastic
Model -
Membrane
Number of connector holes -
0
Pre-stamping -
Surface protection -
Untreated
Thickness -
3 Millimetre
Type -
Straight
Width -
223 Millimetre
