3063158

Photoelectric Sensor, Opposed Mode Sensor (Receiver), Miniature Sensor

Manufacturer's No: VS2AP5R W/30     Manufacturer: Turck Banner
Photoelectric Sensor, Opposed Mode Sensor (Receiver), Miniature Sensor

Availability On Request

POA
  • Type: Photoelectric Sensor (Opposed Mode - Receiver)
  • Miniature sensor with ultra-flat design
  • Operating Voltage: 10-30 VDC
  • Max. Range: 3000 mm
  • Cable Length: 9 m
  • Cable: 2 m, 3-wire
  • Output: PNP switching
  • Suitable for light operation


Product

Manufacturer Material ID -
VS2AP5R W/30
Net Weight -
0.10kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
25.1 Millimetre
Housing material -
Plastic
Length of sensor -
4.7 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
3000 Millimetre
Rated switching distance -
3000 Millimetre
Reaction time -
1 Millisecond
Switching frequency -
500 Hertz
Type of electric connection -
Cable
Type of switch function -
Normally open contact (NO)
Type of switching output -
PNP
Wavelength of the sensor -
940 Nanometre
Width sensor -
12 Millimetre
Turck Banner

Availability On Request

POA
