3063098

VS2 Series: Receiver, Range 1.2 m max, Input: 12-24 V dc, Output: NPN Dark Operate, 3-pin M8 Pigtail QD

Manufacturer's No: VS2RN5RQ     Manufacturer: Turck Banner
VS2 Series: Receiver, Range 1.2 m max, Input: 12-24 V dc, Output: NPN Dark Operate, 3-pin M8 Pigtail QD

Availability On Request

£101.62
  • Type: Photoelectric Sensor (Opposed Mode - Receiver)
  • Design: Miniature sensor with ultra flat design
  • Operating Voltage: 10-30 VDC
  • Maximum Range: 3000 mm
  • Cable Length: 0.15 m, with male end
  • Connector: M8 x 1, 3-pin, PVC, 150 mm
  • Output: NPN switching output
  • Operation: Dark operation


Product

Manufacturer Material ID -
VS2RN5RQ
Net Weight -
0.03kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
25.1 Millimetre
Housing material -
Plastic
Length of sensor -
4.7 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
3000 Millimetre
Rated switching distance -
3000 Millimetre
Reaction time -
1 Millisecond
Switching frequency -
500 Hertz
Type of electric connection -
Connector M8
Type of switch function -
Normally open contact (NO)
Type of switching output -
NPN
Wavelength of the sensor -
940 Nanometre
Width sensor -
12 Millimetre
Turck Banner

Availability On Request

£101.62
