WTS10-12-4016/103/105

Diffuse mode sensor - Detection range: 2 ... 12 mm, Light source: LED, Light type: modulated visible red light , 640 nm, Signal ou

Manufacturer's No: 207057     Manufacturer: Pepperl+Fuchs
Diffuse mode sensor - Detection range: 2 ... 12 mm, Light source: LED, Light type: modulated visible red light , 640 nm, Signal output: switching output PNP NO contact AND logic coupling of both se..

Availability On Request

£347.09
  • Detection range: 2 - 12 mm
  • Light source: LED, modulated visible red light (640 nm)
  • Signal output: switching output PNP NO contact, AND logic coupling of sensor channels, short-circuit and reverse polarity protected
  • Switching type: light-on
  • Connection: 5-pin, M12 x 1 connector
  • Operating voltage: 10 - 30 V DC
  • Ambient temperature: 0 - 50 °C (32 - 122 °F)
  • Switching accuracy maintained if temperature after Teach-In varies by no more than ±7 °C


Product

Manufacturer Material ID -
207057
Net Weight -
0.09kg

Additional Product Information

Commodity Code -
85365019
Country of Origin -
SG
UNSPSC -
41111926
Pepperl+Fuchs

Availability On Request

£347.09
Sign in or Register for customer prices.

Additional Information

Data Sheets

Manuals / Links
