6ES71344GB110AB0

ET200S 2AI, 2 Analogue Input, Current, 13 Bit Standard 4-wire, (terminal type A or B required)

Manufacturer's No: 6ES7134-4GB11-0AB0     Manufacturer: Siemens
ET200S 2AI, 2 Analogue Input, Current, 13 Bit Standard 4-wire, (terminal type A or B required)

View 3D

Availability Back Order

POA
  • Module: ET200S 2AI
  • Inputs: 2 Analogue
  • Input Type: Current
  • Resolution: 13 Bit
  • Wiring: Standard 4-wire (terminal type A or B required)
  • Compatibility: SIMATIC DP
  • Module Width: 15 mm
  • Input Range: +/-20mA
  • Resolution for 4-20mA: 13 bit + sign
  • Resolution for 4-wire transmitter: 12-bit

Read more

  • Cycle Time: 65 ms per channel
  • Fault Indication: SF LED (group fault)

Accessories



Product

Manufacturer Material ID -
6ES7134-4GB11-0AB0
Net Weight -
0.04kg

Additional Product Information

Commodity Code -
85389091
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: EAR99H
Minimum Order Quantity -
1
RoHs Compliance -
Yes
UNSPSC -
32151705

Technical Specification

-
Siemens
Resolution of the analogue outputs -
- Bit
Category according to EN 954-1 -
UN
Performance level acc. EN ISO 13849-1 -
UN
Supply voltage AC 50 Hz -
- Volt
Supply voltage AC 60 Hz -
- Volt
SIL according to IEC 61508 -
UN
Degree of protection (NEMA) -
UN
Degree of protection (IP) -
IP20
Number of interfaces PROFINET -
0
Front build in possible -
Type of electric connection -
Screw-/spring clamp connection
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 3G
Explosion safety category for dust -
None
Analogue inputs configurable -
Degree of protection (IP rating) -
IP20
Depth -
52 Millimetre
Fieldbus connection over separate bus coupler possible -
Front built-in possible -
Height -
81 Millimetre
Input signal, configurable -
Input, current -
Number of analogue inputs -
2
Number of analogue outputs -
0
Number of HW-interfaces industrial Ethernet -
0
Number of HW-interfaces other -
0
Number of HW-interfaces parallel -
0
Number of HW-interfaces PROFINET -
0
Number of HW-interfaces RS-232 -
0
Number of HW-interfaces RS-422 -
0
Number of HW-interfaces RS-485 -
0
Number of HW-interfaces serial TTY -
0
Number of HW-interfaces USB -
0
Number of HW-interfaces Wireless -
0
Rail mounting possible -
Resolution of the analogue inputs -
14 Bit
Supply voltage DC -
20.4 Volt
System accessory -
Voltage type of supply voltage -
DC
Wall mounting/direct mounting -
Width -
15 Millimetre
