6ES76772VB420GB1

SIMATIC ET 200SP CPU 1515SP PC2 T 8 GB, 64-bit

Manufacturer's No: 6ES7677-2VB42-0GB1     Manufacturer: Siemens
SIMATIC ET 200SP CPU 1515SP PC2 T 8 GB, 64-bit

Availability Available to order

£3,460.00
  • SIMATIC ET 200SP Open Controller, CPU 1515SP PC2 T
  • 8 GB RAM (6ES7677-2DB40-0AA0)
  • 128 GB CFast with Windows 10 IoT Enterprise LTSC 2021 64-bit
  • S7-1500 software Controller CPU 1505SP T V3x preinstalled
  • Interfaces: 1x CFast slot, 1x SD/MMC slot, 1x ET 200SP BusAdapter PROFINET connection, 1x 10/100/1000 Mbps Ethernet, 2x USB 3.0, 2x USB 2.0, 1x DisplayPort
  • Documentation and restore image on CFast

Mandatory additional product

Accessories

Product video
Product video


Product

Manufacturer Material ID -
6ES7677-2VB42-0GB1
Net Weight -
1.04kg

Additional Product Information

Commodity Code -
85371091
Country of Origin -
DE
UNSPSC -
39121601

Technical Specification

Bus coupler for modular station connection available -
Degree of protection (IP rating) -
IP20
Depth -
75 Millimetre
Explosion safety category for dust -
None
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 3G
Fieldbus connection over separate bus coupler possible -
Height -
117 Millimetre
Input voltage at DC -
19.2 Volt
Max. input current DC -
2.9 Ampere
Number of HW-interfaces industrial Ethernet -
2
Number of HW-interfaces other -
0
Number of HW-interfaces parallel -
0
Number of HW-interfaces PROFINET -
1
Number of HW-interfaces RS-232 -
0
Number of HW-interfaces RS-422 -
0
Number of HW-interfaces RS-485 -
1
Number of HW-interfaces serial TTY -
0
Number of HW-interfaces USB -
4
Number of HW-interfaces Wireless -
0
Rail mounting possible -
Supporting protocol for ASI -
Supporting protocol for MODBUS -
Supporting protocol for PROFIBUS -
Supporting protocol for PROFINET IO -
Supporting protocol for TCP/IP -
System accessory -
Type of voltage (input voltage) -
DC
Wall mounting/direct mounting -
Width -
160 Millimetre
With integrated power supply -
With pluggable modules, analogue I/O -
With pluggable modules, central modules -
With pluggable modules, communication modules -
With pluggable modules, digital I/O -
With pluggable modules, function and technology modules -
With pluggable modules, others -

Availability Available to order

£3,460.00
