13105 {B}

MultiHop 2.4 GHz 65 mW IP67, 10-30 V dc External Antenna RS485, Inputs: 4 Discrete 2 Analog, Outputs: 4 Discrete 2 Analog

Manufacturer's No: DX80DR2M-H2     Manufacturer: Turck Banner
MultiHop 2.4 GHz 65 mW IP67, 10-30 V dc External Antenna RS485, Inputs: 4 Discrete 2 Analog, Outputs: 4 Discrete 2 Analog

Availability Available to order

£694.59
  • Radio Transmission System with Tree Topology
  • Teilnehmer with RS485 Interface
  • Operating Voltage: 10 to 30 VDC
  • Max. Range: 3200000 mm
  • External Antenna with RG58 RP-SMA Connection
  • Integrated Signal Strength Indicator
  • Configuration via DIP Switch
  • Modbus RTU (RS485) Protocol
  • Self-organizing Tree Structure
  • Repeater for Network Extension

Read more

  • Deterministic Data Transfer
  • Frequency Hopping FHSS
  • Time Division Multiplex Access TDMA
  • Transmission Power: 63 mW (18 dBm conducted, ? 20 dBm EIRP)
  • Inputs: 4 x PNP, 2 x 0 to 20 mA
  • Outputs: 4 x PNP, 2 x 0 to 20 mA
  • Power Consumption: < 60 mA at 24 VDC


Product

Manufacturer Material ID -
DX80DR2M-H2
Net Weight -
0.63kg

Additional Product Information

Commodity Code -
85176200000
Country of Origin -
US
Minimum Order Quantity -
1
UNSPSC -
32151701
Turck Banner

Availability Available to order

£694.59
