757-265/000-010

6-Way Sensor / Actuator Box, 5 Poles, 10M Connecting Cable - Passive

Manufacturer's No: 757-265/000-010     Manufacturer: WAGO
6-Way Sensor / Actuator Box, 5 Poles, 10M Connecting Cable - Passive

Availability Back Order

£179.89
  • Sensor/actuator box
  • M12 connector
  • Compact design
  • Easy to install
  • Suitable for sensor and actuator applications

Accessories

Price £1.15
Back Order


Product

Manufacturer Material ID -
757-265/000-010
Net Weight -
1.33kg

Additional Product Information

Commodity Code -
85389091
Country of Origin -
DE
Minimum Order Quantity -
1
UNSPSC -
39121402

Technical Specification

Max. total current -
- Ampere
Cable outer diameter for cable gland -
- Millimetre
Diameter contact female -
- Millimetre
Type of connector for trunk line -
UN
Connectable conductor cross section -
- Square millimetre
Degree of protection (NEMA) -
UN
Colour housing -
Grey
Material housing -
Plastic
Operation temperature -
-25 Degrees celsius
Degree of protection (IP) -
IP68
Cable length configurable -
Degree of protection (IP rating) -
IP68
Depth -
123 Millimetre
Explosion safety category for dust -
None
Explosion safety category for gas -
None
Fix cable version suitable for cable guide chain -
Height -
26 Millimetre
Housing colour -
Grey
Housing material -
Plastic
Length of the preassembled cable -
10 Metre
Material contact body -
Brass
Material insulation body -
Polyamide (PA)
Material of contact surface -
Gold
Max. current carrying capacity per I/O signal -
2 Ampere
Max. current carrying capacity per socket -
9 Ampere
Number of channels per connector slot -
6
Number of poles sensor/actuator slots -
5
Number of sensor-/actuator-slots -
6
Operating temperature -
-25 Degrees celsius
Operating voltage -
10 Volt
Pollution degree -
3
Rated voltage -
32 Volt
Thread sleeves sensor/actuator slots -
M12
Type of branches for sensor-/actuator cables -
M12
Width -
60 Millimetre
With LED indication -
