757-443/000-002

M8 sensor/actuator box 4-way 3-pole 2m connecting cable

Manufacturer's No: 757-443/000-002     Manufacturer: WAGO
M8 sensor/actuator box 4-way 3-pole 2m connecting cable

Availability Available to order

POA
  • M8 sensor/actuator box
  • 4-way
  • 3-pole
  • 2 meters

Accessories

Spacer module for sensor/actuator box, 4-way

Once added to the cart, you can split this pack for a charge of £16.50

Product Code - 757-040
Price £1.65
Available to order

Marking strips, cut to a defined length, not stretchable, white

Once added to the cart, you can split this pack for a charge of £16.50

Product Code - 757-041
Price £1.03
Available to order


Product

Manufacturer Material ID -
757-443/000-002
Net Weight -
0.22kg

Additional Product Information

Commodity Code -
85365005
UNSPSC -
39121402

Technical Specification

Max. total current -
- Ampere
Cable outer diameter for cable gland -
- Millimetre
Diameter contact female -
- Millimetre
Type of connector for trunk line -
UN
Connectable conductor cross section -
- Square millimetre
Degree of protection (NEMA) -
UN
Colour housing -
Other
Material housing -
Plastic
Operation temperature -
-25 Degrees celsius
Degree of protection (IP) -
IP68
Cable length configurable -
Degree of protection (IP rating) -
IP68
Depth -
117 Millimetre
Explosion safety category for dust -
None
Explosion safety category for gas -
None
Fix cable version suitable for cable guide chain -
Height -
20 Millimetre
Housing colour -
Other
Housing material -
Plastic
Length of the preassembled cable -
2 Metre
Material contact body -
Brass
Material insulation body -
Polyamide (PA)
Material of contact surface -
Gold
Max. current carrying capacity per I/O signal -
2 Ampere
Max. current carrying capacity per socket -
6 Ampere
Number of channels per connector slot -
4
Number of poles sensor/actuator slots -
3
Number of sensor-/actuator-slots -
4
Operating temperature -
-25 Degrees celsius
Operating voltage -
10 Volt
Pollution degree -
3
Rated voltage -
32 Volt
Thread sleeves sensor/actuator slots -
M8
Type of branches for sensor-/actuator cables -
M8
Width -
30 Millimetre
With LED indication -
