1055002

Magnetic Field Sensor, Magnetic-inductive Proximity Sensor

Manufacturer's No: BIM-AKT-Y1X/S235     Manufacturer: Turck Banner
Magnetic Field Sensor, Magnetic-inductive Proximity Sensor

Availability On Request

£71.79
  • Magnetic Field Sensor
  • Magnetic-inductive Proximity Sensor
  • Rectangular shape, height: 15 mm
  • Concentric active face
  • Cable length: 2 m
  • Material: Plastic (PA12-GF30)
  • Increased sensitivity
  • DC 2-wire, nominal voltage: 8.2 VDC
  • Output according to DIN EN 60947-5-6 (NAMUR)
  • Cable connection

Read more

  • ATEX category II 2 G, Ex Zone 1
  • ATEX category II 1 D, Ex Zone 20
  • SIL 2 (Low Demand Mode) according to IEC 61508, PL c according to ISO 13849-1 at HFT0
  • SIL 3 (All Demand Mode) according to IEC 61508, PL e according to ISO 13849-1 with redundant configuration HFT1


Product

Manufacturer Material ID -
BIM-AKT-Y1X/S235
Net Weight -
0.11kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
PL
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-25 Degrees celsius
Construction type housing -
Cuboid
Explosion safety category for dust -
ATEX dust-ex-protection, Cat. 1D
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 2G
Height of sensor -
15 Millimetre
Housing material -
Plastic
Length of sensor -
28 Millimetre
Performance level acc. to EN ISO 13849-1 -
Level c
SIL according to IEC 61508 -
2
Suitable for safety functions -
Type of actuation -
Magnet
Type of electric connection -
Cable
Type of switching output -
NAMUR
Voltage type -
DC
Width sensor -
30 Millimetre
Turck Banner

Availability On Request

£71.79
