DHEB-12-E-U-S-P Bellow gripper

Manufacturer's No: DHEB-12-E-U-S-P     Manufacturer: Festo
DHEB-12-E-U-S-P Bellow gripper

Availability On Request

£234.35
  • Bellow gripper DHEB-12-E-U-S-P
  • Size: 12
  • Stroke of bellows: 5.5 mm
  • Gripping range: 13 mm to 17 mm
  • Single-acting operation
  • Adaptive gripper function
  • Design: Contracting diaphragm with force pilot operated motion sequence
  • Basic guide for positioning
  • Operating pressure: 5 bar (min) to 8 bar (max)
  • Reset pressure: 1 bar

Read more

  • Max. operating frequency: 4 Hz
  • Min. opening time at 0.6 MPa: 20 ms
  • Min. closing time at 0.6 MPa: 40 ms
  • Operating medium: Compressed air to ISO 8573-1:2010 [7:4:4]
  • Lubricated operation possible
  • Corrosion resistance class CRC: 2 (Moderate corrosion stress)
  • LABS (PWIS) conformity: VDMA24364 zone III
  • Ambient temperature: 5°C to 60°C
  • Average bellows replacement interval: 1 year
  • Effective load: 0.12 kg
  • Product weight: 18 g
  • Mounting: Via male thread, lock nut, or either
  • Pneumatic connection: M3
  • RoHS-compliant materials
  • Bellows material: VMQ (silicone)
  • Housing material: Aluminium (anodised)


Product

Manufacturer Material ID -
DHEB-12-E-U-S-P
Net Weight -
0.07kg

Additional Product Information

Commodity Code -
84798997
Country of Origin -
IT
UNSPSC -
30102206
