DHEB-22-E-U-S-P Bellow gripper

Manufacturer's No: DHEB-22-E-U-S-P     Manufacturer: Festo
DHEB-22-E-U-S-P Bellow gripper

Availability On Request

£283.68
  • Bellow gripper DHEB-22-E-U-S-P
  • Size: 22
  • Stroke of bellows: 12 mm
  • Min. ø to be gripped: 24 mm
  • Max. ø to be gripped: 31.5 mm
  • Gripper function: Adaptive
  • Design: Contracting diaphragm
  • Design: Force pilot operated motion sequence
  • Operating pressure: 5 bar, 8 bar
  • Reset pressure: 1 bar

Read more

  • Max. operating frequency of gripper: 4 Hz
  • Min. opening time at 0.6 MPa: 30 ms
  • Min. closing time at 0.6 MPa: 60 ms
  • Operating medium: Compressed air to ISO 8573-1:2010 [7:4:4]
  • Corrosion resistance class CRC: 2 - Moderate corrosion stress
  • LABS (PWIS) conformity: VDMA24364 zone III
  • Ambient temperature: 5°C to 60°C
  • Average replacement interval for the bellows: 1 year
  • Guide value for effective load: 0.32 kg
  • Product weight: 50 g
  • Type of mounting: Via male thread, lock nut, or either
  • Pneumatic connection: M5
  • Material bellows: VMQ (silicone)
  • Material housing: Aluminium, anodised
  • Note on materials: RoHS-compliant
  • Note on operating and pilot medium: Lubricated operation possible
  • Suitable for use with food: See supplementary material information


Product

Manufacturer Material ID -
DHEB-22-E-U-S-P
Net Weight -
0.11kg

Additional Product Information

Commodity Code -
84798997
Country of Origin -
IT
UNSPSC -
30102206
