6GT23910AH30

Antenna cable for ANT 3, ANT 3S and ANT 8 - 3 m

Manufacturer's No: 6GT2391-0AH30     Manufacturer: Siemens
Antenna cable for ANT 3, ANT 3S and ANT 8 - 3 m

Availability Back Order

£102.61
  • Antenna connection cable for SIMATIC RF200/RF300
  • Cable length: 3 meters
  • Trailing plug: M8 straight/M8 angled
  • Material: PUR, UL 758
  • Connects reader to antenna


Product

Manufacturer Material ID -
6GT2391-0AH30
Net Weight -
0.13kg

Additional Product Information

Commodity Code -
85442000
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: N
Minimum Order Quantity -
1
RoHs Compliance -
Yes
UNSPSC -
26121609

Technical Specification

-
Siemens
Screening effectiveness -
- Decibel
Colour -
Black
Screening -
Other
Cable type -
Other
Impedance -
50 Ohm
Length -
3 Metre
Connection type connection 1 -
Plug
Connection type connection 2 -
Elbow plug
Type of connector connection 1 -
Other
Type of connector connection 2 -
Other
Category -
Other
Individual screen type -
None
Min. permitted bending radius, moving application with forced guidance -
44.8 Millimetre
Min. permitted bending radius, moving application/free movement -
44.8 Millimetre
Min. permitted bending radius, stationary application/permanent installation -
44.8 Millimetre
Outer diameter approx. -
5.6 Millimetre
Overall screen type -
Braiding
Permitted cable outer temperature after assembling without vibration -
-40 Degrees celsius
Permitted cable outer temperature during assembling/handling -
-40 Degrees celsius
Sheath colour -
Black
Stranding element -
No

Availability Back Order

£102.61
