6AV78634MB100AA0

SIMATIC IFP2200 (1920 x 1080) MultiTouch, Extended Version(30m), 24vdc/100-240VAC, DisplayPort/DVI incl. Cables.

Manufacturer's No: 6AV7863-4MB10-0AA0     Manufacturer: Siemens
SIMATIC IFP2200 (1920 x 1080) MultiTouch, Extended Version(30m), 24vdc/100-240VAC, DisplayPort/DVI incl. Cables.

Availability On Request

POA
  • Display: SIMATIC IFP2200 Flat Panel 22" with 1920 x 1080 resolution
  • Touch Technology: MultiTouch
  • Extended Version: Supports distances up to 30m
  • Power Input: 24 V DC and 100-240 V AC
  • Interface: DisplayPort/DVI
  • Included Cables: DVI/USB cable (1.8m)


Product

Manufacturer Material ID -
6AV7863-4MB10-0AA0
Net Weight -
9.60kg

Additional Product Information

Commodity Code -
85371099
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: N
Minimum Order Quantity -
1
RoHs Compliance -
Yes
UNSPSC -
43211900

Technical Specification

Horizontal frequency -
- kiloHertz
Frame frequency -
- kiloHertz
Number of grey-scales/blue-scales of display -
-
Built-in depth -
62.5 Millimetre
Operation temperature -
0 Degrees celsius
Front build in possible -
Type of display -
TFT
Degree of protection (IP), front side -
IP65
Front built-in possible -
Height of the front -
380 Millimetre
Mouse-cursor control integrated -
Number of colours of the display -
16777216
Number of function buttons -
0
Number of pixels, horizontal -
1920
Number of pixels, vertical -
1080
Operating temperature -
0 Degrees celsius
Recess depth -
62.5 Millimetre
Screen diagonal -
21.5 inch
Supply voltage AC 50 Hz -
90 Volt
Supply voltage AC 60 Hz -
90 Volt
Supply voltage DC -
19.2 Volt
Voltage type of supply voltage -
AC/DC
Width of the front -
560 Millimetre
With colour display -
With HW-interface digital video signal -
With HW-interface USB -
With touch screen -

Availability On Request

POA
