6SL32111PE218AL0

SINAMICS Power Module PM240-2 with integrated Class A filter with integrated braking chopper 380-480

Manufacturer's No: 6SL3211-1PE21-8AL0     Manufacturer: Siemens
SINAMICS Power Module PM240-2 with integrated Class A filter with integrated braking chopper 380-480

Availability On Request

POA
  • SINAMICS Power Module PM240-2
  • Integrated Class A filter
  • Integrated braking chopper
  • Voltage: 380-480 V 3 AC +/-10%
  • Power high overload: 5.5 kW at 200% for 3s, 150% for 57s, 100% for 240s
  • Power low overload: 7.5 kW at 150% for 3s, 110% for 57s, 100% for 240s
  • Ambient temperature: -10 to +50°C
  • Dimensions: 345 x 154 x 171 mm (H x W x D)
  • Degree of protection: IP20-PT
  • Does not include Control Unit and operating unit

Read more

  • Released with CU firmware version V4.6

Selectable mandatory product

Accessories

Question and Answer (Q&A video)
Question and Answer (Q&A video)


Product

Manufacturer Material ID -
6SL3211-1PE21-8AL0
Net Weight -
3.98kg

Additional Product Information

Commodity Code -
85044084
Country of Origin -
GB
Export Control Regulations -
3A999A / 9I999IR
Minimum Order Quantity -
1
UNSPSC -
32121705

Technical Specification

Number of digital inputs -
-
Number of digital outputs -
-
Number of analogue inputs -
-
Number of analogue outputs -
-
Number of HW-interfaces industrial Ethernet -
-
Number of HW-interfaces RS-232 -
-
Number of HW-interfaces RS-422 -
-
Number of HW-interfaces RS-485 -
-
Number of HW-interfaces serial TTY -
-
Number of HW-interfaces USB -
-
Number of HW-interfaces parallel -
-
Number of HW-interfaces other -
-
Number of interfaces PROFINET -
-
Max. output voltage -
- Volt
Degree of protection (NEMA) -
UN
Degree of protection (IP) -
IP20
Mains frequency -
50/60 Hz
Application in industrial area permitted -
Depth -
171 Millimetre
Height -
345 Millimetre
Integrated breaking resistance -
Mains voltage -
380 Volt
Max. output at linear load at rated output voltage -
5.5 Kilowatt
Max. output at quadratic load at rated output voltage -
7.5 Kilowatt
Max. output frequency -
550 Hertz
Nominal output current I2N -
18 Ampere
Number of phases input -
3
Number of phases output -
3
Relative symmetric net frequency tolerance -
5 Percentage
Relative symmetric net voltage tolerance -
-10 Percentage
Type of converter -
U converter
Width -
154 Millimetre
-
- SINAMICS Power Module PM240-2 - Integrated Class A filter - Integrated braking chopper - Voltage: 380-480 V 3 AC +/-10% - Power high overload: 5.5 kW at 200% for 3s, 150% for 57s, 100% for 240s - Power low overload: 7.5 kW at 150% for 3s, 110% for 57s, 100% for 240s - Ambient temperature: -10 to +50°C - Dimensions: 345 x 154 x 171 mm (H x W x D) - Degree of protection: IP20-PT - Does not include Control Unit and operating unit - Released with CU firmware version V4.6 Millimetre

Availability On Request

POA
