IWLAN access point, IEEE 802.11n, 150 Mbit/s, RJ45, 1xRadio, 1xR-SMA

6GK57611FC000AA0

IWLAN access point, IEEE 802.11n, 150 Mbit/s, RJ45, 1xRadio, 1xR-SMA

Produced by Siemens

Availability Back Order

Price - £725.00
IWLAN Access Point, SCALANCE W761-1 RJ45, 1 radio, 1 R-SMA antenna port, IEEE 802.11a/b/g/h/n, 2.4/5GHz, gross data rate 150 Mbit/s, 1x RJ45 max. 100 Mbit/s, 24 V DC, joint block, IP20, 0... +55 °C, WPA2/802.11i/e, observe national approvals! CERT ID: ELN-W1-RJ-E1, scope of delivery: Manuals on CD-ROM German/English, 1x joint block; for operation outside of USA/Israel . SCALANCE W761-1 RJ45 1x wireless, 1x R-SMA antenna port, IEEE 802.11a/b/g/h/n, 2.4/5 GHz, gross data rate 150 Mbps, 1x RJ45 max. 100 Mbps, 24 V DC, terminal block, IP20, for operation outside the US/Israel. For space-saving installation in the control cabinet on standard DIN rail. 1 unit.Access Point with a built-in wireless interface for installation in control cabinets in industrial plants, such as suspended monorails and automatic guided vehicle systems. The device enables wireless commissioning in the plant.Implementation of simple and cost-effective wireless machine networking. Predictable data traffic (deterministic response) and defined response times on the wireless link as well as reliable wireless connection. Particularly future-proof through conformity with universally accepted WLAN standard IEEE 802.11. Wireless access for service and maintenance, light and small design for efficient usage in automatic guided vehicle systems (AGV), expandable with video data. Space-saving installation thanks to SIMATIC design.The comprehensive accessories include a wide antenna portfolio, plug-in connectors, stripping tools, mounting accessories as well as cabling technology that top off the system.
No alternatives available for this product.
Product
Manufacturer Material ID -
6GK5761-1FC00-0AA0
Net Weight -
0.23kg
Additional Product Information
Commodity Code -
85176200
Country of Origin -
DE
Export Control Regulations -
AL: 5A002A1A2 / ECCN: 5A002ENCU
Minimum Order Quantity -
1
RoHs Compliance -
Yes
UNSPSC -
32151701
Technical Specification
Width -
0.05 Millimetre
Height -
0.114 Millimetre
Depth -
0.074 Millimetre
Max. data transmission rate -
150 Megabit per second
Number of ports 10/100 Mbps LAN -
1
Frequency band -
2.4 GHz and 5 GHz
Number of users -
28
