6XV18303DH30

PROFIBUS M12 plug-in cable, (ET 200) pre-assembled PB FC trail. Cable+2 M12 connector, 3.0 m

Manufacturer's No: 6XV1830-3DH30     Manufacturer: Siemens
PROFIBUS M12 plug-in cable, (ET 200) pre-assembled PB FC trail. Cable+2 M12 connector, 3.0 m

Availability Back Order

£31.00
  • Pre-assembled PROFIBUS M12 plug-in cable (ET 200)
  • Trailing cable with 2 M12 connectors, B-coded, 5-pole
  • Length: 3 meters


Product

Manufacturer Material ID -
6XV1830-3DH30
Net Weight -
0.29kg

Additional Product Information

Commodity Code -
85444210
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: N
Minimum Order Quantity -
1
RoHs Compliance -
Yes
UNSPSC -
26121609

Technical Specification

-
Siemens
Nominal cross section conductor -
- Square millimetre
AWG-size -
-
NVP value -
- Percentage
Smoke development class according to EN 13501-6 -
UN
Euro class flaming droplets/particles according to EN 13501-6 -
UN
Euro class acidity according to EN 13501-6 -
UN
Min. permitted bending radius, moving application with forced guidance -
- Millimetre
Min. permitted bending radius, moving application/free movement -
- Millimetre
Min. permitted bending radius, stationary application/permanent installation -
- Millimetre
Specification core insulation -
UN
Colour outer sheath -
Other
Diameter conductor -
0.67 Millimetre
Screen over stranding element -
None
Screen over stranding -
Foil + braiding
Material outer sheath -
Polyurethane (PUR)
Reaction-to-fire class according to EN 13501-6 -
None
Specification material outer sheath -
Other
Core insulation material -
Other
Flame retardant -
No
Circuit integrity -
No
Sheath colour -
Other
Sheath material -
Polyurethane (PUR)
Conductor category -
Class 5 = flexible
Protective sheath -
No
Stranding -
Bundle
Reaction-to-fire according to EN 13501-6: Class -
None
Sheath material specification -
Other
Category -
Other
Conductor Diameter -
0.67 Millimetre
Conductor surface -
Bare
Core identification -
Colour
Individual screen type -
None
Number of cores -
2
Number of stranding elements -
1
Outer diameter approx. -
8 Millimetre
Overall screen type -
Foil + braiding
Permitted cable outer temperature after assembling without vibration -
-40 Degrees celsius
Permitted cable outer temperature during assembling/handling -
-40 Degrees celsius
Stranding element -
Pairs

Availability Back Order

£31.00
