KMP3-25P-16-10 Connecting cable

Manufacturer's No: KMP3-25P-16-10     Manufacturer: Festo
KMP3-25P-16-10 Connecting cable

Availability On Request

£127.31
  • Product: KMP3-25P-16-10 Connecting Cable
  • Cable Type: Sub-D socket (hood for CPV)
  • Cable Length: 10 m
  • Number of Pins/Wires: 25
  • Cable Diameter: 8.5 mm
  • Cross-Sectional Area: 0.34 mm²
  • Electrical Connections: 18 pins/wires
  • Operational Voltage Range: 0 V to 30 V DC
  • Nominal Operating Voltage: 24 V DC
  • Current Rating: 3 A at 40°C

Read more

  • Immunity to Surge: 1 KV
  • Bending Radius: 45 mm (fixed), 90 mm (moving)
  • Protection Rating: IP65
  • Temperature Range: -25°C to 70°C (ambient), -5°C to 70°C (moving cable), -25°C to 75°C (storage)
  • Material: PVC cable sheath, PA housing, NBR seals, gold-plated copper alloy electrical contacts
  • Compliance: RoHS, CE mark, UKCA marking, LABS (PWIS) conformity
  • Cable Sheath Color: Grey
  • Cable Structure: 18 x 0.34 mm²
  • Connector System: Sub-D
  • Mounting: 2x screw M3
  • Frequency of Connection: 50
  • Pollution Degree: 3


Product

Manufacturer Material ID -
KMP3-25P-16-10
Net Weight -
0.00kg

Additional Product Information

Commodity Code -
85444290
Country of Origin -
DE
UNSPSC -
30102206
