Ultrasonic Sensor, Level Control

Manufacturer's No: LUS211-40-51-2UPN8-H1141     Manufacturer: Turck Banner
Ultrasonic Sensor, Level Control

Availability On Request

£471.46
  • Ultrasonic Sensor for Level Control
  • Operating Voltage: 18-33 VDC
  • Max. Range: 400 mm
  • 4-digit, 2-colored, 12-segment display
  • Display rotatable by 180°
  • Housing rotatable after mounting the process connection
  • Process Connection: G3/4"
  • Sealing ring included (stainless steel ring with NBR seal)
  • Blind Zone: 0.5 cm
  • Range: 40 cm

Read more

  • Resolution: 0.5 mm
  • Aperture Angle of Sonic Cone: ±15°
  • 2 switching outputs (PNP/NPN, NO/NC programmable)
  • Transmission of process value and parametrization via IO-Link


Product

Manufacturer Material ID -
LUS211-40-51-2UPN8-H1141
Net Weight -
0.38kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
DE
UNSPSC -
39122216
Turck Banner

Availability On Request

£471.46
