Ultrasonic Sensor, Level Control

Manufacturer's No: LUS211-40-51-LI2UPN8-H1141     Manufacturer: Turck Banner
Ultrasonic Sensor, Level Control

Availability On Request

£565.49
  • Ultrasonic Sensor for Level Control
  • Operating voltage: 18-33 VDC
  • Max. range: 400 mm
  • 4-digit, 2-colored, 12-segment display
  • Display rotatable by 180°
  • Housing rotatable after mounting the process connection
  • Process connection: G3/4"
  • Sealing ring included (stainless steel ring with NBR seal)
  • Blind zone: 0.5 cm
  • Range: 40 cm

Read more

  • Resolution: 0.5 mm
  • Aperture angle of sonic cone: ±15°
  • 1 switching output (PNP/NPN)
  • 1 analog output: 4-20 mA / 0-10 V
  • Additional switching output (PNP/NPN, NO/NC programmable)
  • Transmission of process value and parametrization via IO-link


Product

Manufacturer Material ID -
LUS211-40-51-LI2UPN8-H1141
Net Weight -
0.38kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
DE
UNSPSC -
39122216
Turck Banner

Availability On Request

£565.49
