3RA24378XE321NB3

Contactor assembly for star-delta (wye-delta) start with IO-Link AC 3: 55 kW/400 V 20-33 V AC/DC, 3 NO + 3 NC

Manufacturer's No: 3RA2437-8XE32-1NB3     Manufacturer: Siemens
Contactor assembly for star-delta (wye-delta) start with IO-Link AC 3: 55 kW/400 V 20-33 V AC/DC, 3 NO + 3 NC

Availability Available to order

£1,303.96
  • Contactor assembly for star-delta (wye-delta) start
  • I/O-Link AC-3
  • 55 kW / 400 V
  • 20-33 V AC/DC
  • 3-pole, Size S2
  • Screw terminal
  • Electrical and mechanical interlock
  • 3 normally open (NO) + 3 normally closed (NC) integrated contacts

Accessories

Component part

Presentation video
Question and Answer (Q&A video)
Question and Answer (Q&A video)
Question and Answer (Q&A video)
Presentation video


Product

Manufacturer Material ID -
3RA2437-8XE32-1NB3
Net Weight -
4.66kg

Additional Product Information

Commodity Code -
85364900
Country of Origin -
DE
RoHs Compliance -
Yes
UNSPSC -
39121529

Technical Specification

Rated operation power NEMA -
- Kilowatt
Rated control supply voltage Us at AC 50HZ -
20 Volt
Rated control supply voltage Us at AC 60HZ -
20 Volt
Rated control supply voltage Us at DC -
20 Volt
Degree of protection (IP) -
IP20
Degree of protection (IP rating) -
IP20
Degree of protection (NEMA) -
Other
Function -
Star-delta contactor
Number of main contacts as normally open contact -
3
Number of normally closed contacts as main contact -
0
Rated control supply voltage at AC 50 Hz -
20 Volt
Rated control supply voltage at AC 60 Hz -
20 Volt
Rated control supply voltage at DC -
20 Volt
Rated operation current Ie at AC-3, 400 V -
115 Ampere
Rated operation power at AC-3, 400 V -
55 Kilowatt
Type of electrical connection of main circuit -
Screw connection
Voltage type for actuating -
AC/DC

Availability Available to order

£1,303.96
