789-552

Relay module, Nominal input voltage: 24 V AC/DC, 4 make contacts, gray

Manufacturer's No: 789-552     Manufacturer: WAGO
Relay module, Nominal input voltage: 24 V AC/DC, 4 make contacts, gray

Availability Available to order

Once added to the cart, you can split this pack for a charge of £16.50

POA
  • Relay module for 24 V AC/DC nominal input voltage
  • 4 make contacts with a limiting continuous current of 4 A
  • Red status indicator for easy monitoring
  • Module width of 18 mm
  • Terminal capacity of 2.50 mm²
  • Color: gray


Product

Manufacturer Material ID -
789-552
Net Weight -
0.59kg

Additional Product Information

Commodity Code -
85365005
Country of Origin -
DE
UNSPSC -
39121529

Technical Specification

Rated control supply voltage Us at AC 50HZ -
24 Volt
Rated control supply voltage Us at AC 60HZ -
24 Volt
Rated control supply voltage Us at DC -
24 Volt
Degree of protection (IP) -
IP20
Complete with socket -
Degree of protection (IP rating) -
IP20
Depth -
90 Millimetre
Drive, polarization -
Polarity free
Drive, switching attitude -
Mono stable
Height -
90 Millimetre
Nominal current -
4 Ampere
Number of contacts as change-over contact -
0
Number of contacts as normally closed contact -
0
Number of contacts as normally open contact -
4
Rated control supply voltage at AC 50 Hz -
24 Volt
Rated control supply voltage at AC 60 Hz -
24 Volt
Rated control supply voltage at DC -
24 Volt
Type of electric connection -
Spring clamp connection
Type of switch contact -
Double contact
Voltage type for actuating -
AC/DC
Width -
17.5 Millimetre
With LED indication -
