551402

SIES-8M-NO-24V-K-0,3-M8D Proximity sensor

Manufacturer's No: SIES-8M-NO-24V-K-0,3-M8D     Manufacturer: Festo
SIES-8M-NO-24V-K-0,3-M8D Proximity sensor

Availability Available to order

£65.39
  • Proximity sensor with special design for T-slot applications
  • NPN, N/C contact, 24 V DC, LED switching status
  • Standard 0.3 m cable suitable for energy chains, M8x1 A-coded plug
  • Conforms to EN 60947-5-2 standard, RCM trademark approved
  • Measured variable: Position, inductive measuring principle
  • Rated operating distance: 1.5 mm, suitable for various materials
  • Ambient temperature range: -25°C to 70°C
  • Switching output: NPN, N/C contact, switching time 0.0001 ms
  • Max. switching frequency: 4500 Hz, max. output current 150 mA
  • Max. switching capacity: 4.5 W, voltage drop: 2 V

Read more

  • Integrated inductive protective circuit, overload protection available
  • Operational voltage range: 10 V to 30 V, residual ripple: 10%
  • Electrical connection: M8x1 A-coded plug, 3 cores, screw-type lock
  • Cable length: 0.3 m, grey TPE-U(PU) sheath, gold-plated brass contacts
  • Housing materials: Brass, nickel-plated, PA, PUR, high-alloy stainless steel
  • Yellow LED switching status indication
  • IP65 and IP67 degree of protection, suitable for moderate corrosion stress
  • Immunity to surge: 0.8 kV, insulation voltage: 50 V
  • Cleanroom class 4 according to ISO 14644-1, pollution degree: 3


Product

Manufacturer Material ID -
SIES-8M-NO-24V-K-0,3-M8D
Net Weight -
0.02kg

Additional Product Information

Commodity Code -
85365019
Country of Origin -
LK
UNSPSC -
31251501
