SMT-8M-A-PO-24V-E-7,5-OE Proximity sensor

Manufacturer's No: SMT-8M-A-PO-24V-E-7,5-OE     Manufacturer: Festo
SMT-8M-A-PO-24V-E-7,5-OE Proximity sensor

Availability On Request

£39.75
  • Proximity sensor SMT-8M-A-PO-24V-E-7,5-OE
  • Insertable in T-slot from above
  • Contactless (solid state)
  • Operating voltage: 24 V DC
  • Cable length: 7.5 m, suitable for energy chains/robots
  • Design for T-slot, based on EN 60947-5-2 standard
  • Approval: RCM trademark, c UL us listed (OL), CE mark
  • Special characteristics: Oil resistant, RoHS-compliant, halogen-free
  • Measured variable: Position
  • Measuring principle: Magneto-resistive

Read more

  • Temperature range: -40°C to 85°C
  • Repetition accuracy: 0.2 mm
  • Switching output: PNP, N/C contact
  • Switch-on time: 1.3 ms, switch-off time: 7.3 ms
  • Max. switching frequency: 130 Hz, max. output current: 100 mA
  • Max. switching capacity: 2.8 W, voltage drop: 1.5 V
  • Short circuit current rating, overload protection
  • Reverse polarity protection for all electrical connections
  • Cable: TPE-U(PUR) sheath, grey color, suitable for energy chains/robot applications
  • Material: PA-reinforced housing, high-alloy stainless steel
  • LEDs for switching status and function reserve indication
  • Degree of protection: IP65, IP68, IP69K
  • LABS (PWIS) conformity: VDMA24364-B2-L
  • Cleanroom class: Element installed statically, no meaningful evaluation possible


Product

Manufacturer Material ID -
SMT-8M-A-PO-24V-E-7,5-OE
Net Weight -
0.09kg

Additional Product Information

Commodity Code -
85365019
Country of Origin -
TR
UNSPSC -
41111926
Festo

Availability On Request

£39.75
