50141322

Scanning system: Against object; Special version: Activation input, Deactivation input, Teach input; Light source: Laser, Red; Lig

Manufacturer's No: ODS9L1.8/LAK-450-M12     Manufacturer: Leuze
Scanning system: Against object; Special version: Activation input, Deactivation input, Teach input; Light source: Laser, Red; Light spot size: 1 mm; Measurement range: 50 ... 450 mm; Geometric resol

Availability Back Order

£861.00
  • Scanning system: Against object
  • Special version: Activation input, Deactivation input, Teach input
  • Light source: Laser, Red
  • Light spot size: 1 mm
  • Measurement range: 50
  • 450 mm
  • Geometric resolution: 0.1 mm
  • Accuracy: 0%
  • Supply voltage: 18
  • 30 V DC

Read more

  • Digital switching inputs: 1 Piece
  • Analog outputs: 1 Piece
  • Digital switching outputs: 1 Piece
  • Output: Configurable, factory setting
  • current
  • Interface: IO-Link
  • Connection: Connector, M12, 5-pin, Turning, 90°
  • Dimensions: 21 mm x 50 mm x 50 mm
  • Operational controls: Control buttons, PC software

Accessories



Product

Manufacturer Material ID -
ODS9L1.8/LAK-450-M12
Net Weight -
0.10kg

Additional Product Information

Commodity Code -
90318020
Country of Origin -
DE
UNSPSC -
39121528

Technical Specification

Thumbnail of product picture -
Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Explosion safety category for dust -
None
Explosion safety category for gas -
None
Height of sensor -
50 Millimetre
Housing material -
Plastic
Laser protection class -
Class 1
Length of sensor -
50 Millimetre
Material of cable sheath -
Other
Material of optical surface -
Glass
Measuring principle for optical distance measurement -
Triangulation
Operation agent-safety class -
Safety class 3
Relative accuracy of measurement -
0 Percentage
Relative linearity deflection -
1 Percentage
Scanning principle -
Push button
Sensing mode -
Light-/dark switching
Setting procedure -
Manual adjustment
Supply voltage -
18 Volt
Type of analogy output -
0 mA ... 20 mA / 4 mA ... 20 mA
Type of electric connection -
Connector M12
Type of light -
Laser diode, red light
Type of switch function -
Anticoincidence
Type of switching output -
PNP/NPN
Voltage type -
DC
Width sensor -
21 Millimetre
Leuze

Availability Back Order

£861.00
