QM26 Washdown Series: Adjustable BGS (Large Red LED), Range: 400, Input 10-30 V dc, Output: Complementary Solid-State PNP, 200 (7.

Manufacturer's No: QM26VPAF400Q5     Manufacturer: Turck Banner
QM26 Washdown Series: Adjustable BGS (Large Red LED), Range: 400, Input 10-30 V dc, Output: Complementary Solid-State PNP, 200 (7.5 in) M12 Pigtail QD

Availability On Request

£281.28
  • Photoelectric sensor in diffuse mode
  • Adjustable background suppression
  • Operating voltage: 10-30 VDC
  • Max. range: 400 mm
  • Cable length: 0.15 m
  • Detection range: 5 mm to 800 mm


Product

Manufacturer Material ID -
QM26VPAF400Q5
Net Weight -
0.07kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
DE
UNSPSC -
39122216

Technical Specification

Adjustment range -
5 Millimetre
Ambient temperature -
-30 Degrees celsius
Construction type housing -
Cuboid
Height of sensor -
32.6 Millimetre
Housing material -
Metal
Length of sensor -
15.3 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Other
Max. switching distance -
400 Millimetre
Rated switching distance -
400 Millimetre
Reaction time -
0.5 Millisecond
Type of electric connection -
Connector M12
Type of light -
Polarity free red light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
PNP
Wavelength of the sensor -
620 Nanometre
Width sensor -
14 Millimetre
Turck Banner

Availability On Request

£281.28
