QMH26 Hygienic Series: Adjustable BGS (Small Red LED), Range: 200, Input: 10-30 V dc, Output: Complementary Solid-State PNP M8, 4-

Manufacturer's No: QMH26VPAF200Q7     Manufacturer: Turck Banner
QMH26 Hygienic Series: Adjustable BGS (Small Red LED), Range: 200, Input: 10-30 V dc, Output: Complementary Solid-State PNP M8, 4-pin M8 Integral QD

Availability On Request

£338.45
  • Photoelectric sensor in diffuse mode
  • Adjustable background suppression
  • Operating voltage: 10-30 VDC
  • Maximum range: 200 mm
  • Detection range: 5-800 mm


Product

Manufacturer Material ID -
QMH26VPAF200Q7
Net Weight -
0.06kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
DE
UNSPSC -
39122216

Technical Specification

Adjustment range -
5 Millimetre
Ambient temperature -
-30 Degrees celsius
Construction type housing -
Cuboid
Height of sensor -
32.6 Millimetre
Housing material -
Metal
Length of sensor -
20.3 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Other
Max. switching distance -
200 Millimetre
Rated switching distance -
200 Millimetre
Reaction time -
0.5 Millisecond
Type of electric connection -
Connector M8
Type of light -
Polarity free red light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
PNP
Wavelength of the sensor -
660 Nanometre
Width sensor -
14 Millimetre
Turck Banner

Availability On Request

£338.45
