100000204

Miniature Encoder, With Analog Output, Premium Line

Manufacturer's No: RI60P1-QR20-LU4X2-H1141     Manufacturer: Turck Banner
Miniature Encoder, With Analog Output, Premium Line

Availability On Request

£141.15
  • Miniature encoder with analog output
  • Operating voltage: 8-30 VDC
  • Rectangular plastic housing, compact and robust
  • Versatile mounting options
  • Positioning element P1-RI-QR20 included
  • Suitable for vehicle board nets (12V and 24V)
  • Increased interference immunity: 100 V/m
  • Protection against conducted interference according to DIN ISO 7637-2 (SAE J 113-11)
  • Extended temperature range
  • High protection class IP68/IP69K

Read more

  • Resistant to salt spray and rapid temperature changes
  • Measuring range displayed via LED
  • Immune to electromagnetic interference
  • Resolution: 0.09°
  • 3-wire connection
  • Analog output: 0.5-4.5 V
  • Output: 5 V (typical) without RLC coupling


Product

Manufacturer Material ID -
RI60P1-QR20-LU4X2-H1141
Net Weight -
0.10kg

Additional Product Information

Commodity Code -
90318020000
Country of Origin -
DE
UNSPSC -
39121402

Technical Specification

Degree of protection (IP rating) -
IP68
Diameter axle -
6 Millimetre
Housing material -
Plastic
Model -
Other
Physical measurement principle -
Inductive
Programmable -
Standard for interfaces -
Analogue
Type of electric connection -
Plug-in connection
Type of shaft encoder -
Hollow shaft
Turck Banner

Availability On Request

£141.15
