2CDS273061R0024

S203M-C2UC Miniature Circuit Breaker - 3P - C - 2 A

Manufacturer's No: S203M-C2UC     Manufacturer: ABB
S203M-C2UC Miniature Circuit Breaker - 3P - C - 2 A

Availability On Request

£352.39
  • Miniature Circuit Breaker S203M-C2UC
  • 3 poles
  • Current rating: 2 A
  • Suitable for DC and AC applications
  • High short circuit breaking capacity
  • Compliant with major international and local standards
  • Compatible with System pro M compact® accessories
  • Simple and flexible solution for various applications


Product

Manufacturer Material ID -
S203M-C2UC
Net Weight -
0.40kg

Additional Product Information

Commodity Code -
85362010
Country of Origin -
DE
UNSPSC -
39122330

Technical Specification

Built-in depth -
69 Millimetre
Release characteristic -
C
Degree of protection (IP) -
IP20
Additional equipment possible -
Ambient temperature during operating -
-25 Degrees celsius
Connectable conductor cross section multi-wired -
0.75 Square millimetre
Connectable conductor cross section solid-core -
0.75 Square millimetre
Current limiting class -
3
Degree of protection (IP rating) -
IP20
Frequency -
50 Hertz
Number of poles (total) -
3
Number of protected poles -
3
Over voltage category -
3
Pollution degree -
3
Power loss -
4.35 Watt
Rated current -
2 Ampere
Rated impulse-withstand voltage (Uimp) -
4 Kilovolt
Rated insulation voltage Ui -
440 Volt
Rated short-circuit breaking capacity Icn EN 60898 at 230 V -
10 kiloampere
Rated short-circuit breaking capacity Icn EN 60898 at 400 V -
10 kiloampere
Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V -
25 kiloampere
Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V -
10 kiloampere
Rated voltage -
400 Volt
Recess depth -
69 Millimetre
Tripping characteristic (type/curve) -
C
Voltage type -
Other
Width in number of modular spacings -
3
