72126 {B}

WORLD-BEAM Q12 Series: Retroreflective, Range: 1.5 m, Input: 10-30 V dc, Output: DO (Dark Operate) Bipolar: 1 NPN, 1 PNP, 150 (6 i

Manufacturer's No: Q12RB6LVQ     Manufacturer: Turck Banner
WORLD-BEAM Q12 Series: Retroreflective, Range: 1.5 m, Input: 10-30 V dc, Output: DO (Dark Operate) Bipolar: 1 NPN, 1 PNP, 150 (6 in) M8 Pigtail QD

Availability Available to order

£134.92
  • Photoelectric Sensor (Retroreflective, Miniature)
  • Operating Voltage: 10-30 VDC
  • Max. Range: 1500 mm
  • Cable Length: 0.15 m, PVC material
  • Cable with M8 x 1 male end, 4-pin
  • Protection Class: IP67
  • LED visible from all angles
  • Indicates insufficient excess gain
  • Switching Output: Bipolar, dark operation


Product

Manufacturer Material ID -
Q12RB6LVQ
Net Weight -
0.02kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
Minimum Order Quantity -
1
UNSPSC -
39121528

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
26.6 Millimetre
Housing material -
Plastic
Length of sensor -
12.4 Millimetre
Material of optical surface -
Plastic
Max. switching distance -
1500 Millimetre
Rated switching distance -
1500 Millimetre
Reaction time -
0.7 Millisecond
Sensing mode -
Dark switching
Switching frequency -
700 Hertz
Type of electric connection -
Connector M8
Type of light -
Polarity free red light
Type of switch function -
Normally open contact (NO)
Type of switching output -
PNP/NPN
Wavelength of the sensor -
640 Nanometre
Width sensor -
8 Millimetre
Turck Banner

Availability Available to order

£134.92
