7TCA091720R0193

PRIMEVO ESC R. S. MT 100 ST

Manufacturer's No: SM100ST     Manufacturer: ABB
PRIMEVO ESC R. S. MT 100 ST

Availability On Request

£47.03
  • Model: PRIMEVO ESC R. S. MT 100 ST
  • Luminaire Type: Self-contained for escape route lighting with long beam
  • System Consumption: 4.8 watts
  • Warranty: 3 years (excluding battery)


Product

Manufacturer Material ID -
SM100ST
Net Weight -
0.51kg

Additional Product Information

Commodity Code -
9405490000
Country of Origin -
CN
UNSPSC -
39122330

Technical Specification

Labelling type -
Sticker
Type of indicator -
Single-sided
Wiring system -
Continuous circuit/emergency circuit
Lamp included -
Luminous flux in standby mode -
140 Lumen
Battery chemistry -
NiCd
Colour temperature -
4000 Kelvin
Connection type -
Other
Constant luminous flux control -
Control gear -
Electronic transformer
Cover material -
Plastic matt/satinised
Degree of protection (IP rating) -
IP20
Function -
Escape route lighting
Height/depth -
57 Millimetre
Housing colour -
White
Housing material -
Plastic
Impact resistance (IK rating) -
IK10
Length -
140 Millimetre
Light distribution -
Other
Light source included -
Light source type -
LED non-replaceable
Maximum system power -
4.5 Watt
Monitoring equipment -
Automatic self test
Mounting method -
Ceiling surface mounting
Nominal operation time -
3 Hour
Nominal voltage -
220 Volt
Number of lamps -
2
Number of lighting heads -
1
Number of poles -
3
Outer diameter -
140 Millimetre
Power factor -
0.6
Power supply system -
Peripheral (individual battery)
Protection class -
II
Rated ambient temperature acc. IEC62722-2-1 -
0 Degrees celsius
Rated luminous flux acc. IEC 62722-2-1 -
120 Lumen
Type of cabling -
Suitable for through wiring
Voltage type -
AC
Width -
140 Millimetre
ABB

Availability On Request

£47.03
