THT male header, 1.0 x 1.0 mm solder pin, straight, Pin spacing 5 mm, 6-pole, gray

231-136/001-000

THT male header, 1.0 x 1.0 mm solder pin, straight, Pin spacing 5 mm, 6-pole, gray

Produced by WAGO

Availability Back Order

Once added to the cart, you can split this pack for a charge of £16.50

Price - £1.14
Male connector with straight solder pins 6-pole Pin spacing 5 mm / 0.197 in Vertical PCB mounting with closed end

Data Sheets

231-102/102-000

Female Connector, With Integrated End Plate 2-Pole Gray

Once added to the cart, you can split this pack for a charge of £16.50

£1.21
Back Order

231-103/102-000

Female Connector, With Integrated End Plate 3-Pole Gray

Once added to the cart, you can split this pack for a charge of £16.50

£1.68
Back Order
No alternatives available for this product.
Product
Manufacturer Material ID -
231-136/001-000
Net Weight -
0.00kg
Additional Product Information
Commodity Code -
85366990
Country of Origin -
DE
Minimum Order Quantity -
100
RoHs Compliance -
YES
UNSPSC -
39121402
Technical Specification
Operation temperature -
-60 Degrees celsius
Rated voltage -
320 Volt
Number of poles -
6
Operating temperature -
-60 Degrees celsius
Rated surge voltage -
4 Kilovolt
Pollution degree -
2
Length pin -
5 Millimetre
Modular spacing connections -
5 Millimetre
Number of plug-in contact rows -
1
Suitable for PCB thickness -
1.5 Millimetre
Modular spacing contacts -
5 Millimetre
Angle PCB/contact -
90° (upwards vertical)
Rated current In -
12 Ampere

Additional Information

Data Sheets
