734-132

Male header (for PCBs) Straight solder pin 1 x 1 mm 2-pole Pin spacing 3.5 mm / 0.138 in 100% protected against mismating with clo

Manufacturer's No: 734-132     Manufacturer: WAGO
Male header (for PCBs) Straight solder pin 1 x 1 mm 2-pole Pin spacing 3.5 mm / 0.138 in 100% protected against mismating with closed end Vertical PCB mounting

Availability Available to order

Once added to the cart, you can split this pack for a charge of £16.00

£0.48
  • THT male header
  • 1.0 x 1.0 mm solder pin, straight
  • Pin spacing: 3.5 mm
  • 2-pole
  • 100% protected against mismating
  • Color: light gray

Accessories

Coding key, to be snapped above top level, white

Once added to the cart, you can split this pack for a charge of £16.50

Product Code - 734-130
Price £0.08
Available to order

Coding key, to be snapped above top level, black

Once added to the cart, you can split this pack for a charge of £16.50

Product Code - 734-159
Price POA
Available to order


Product

Manufacturer Material ID -
734-132
Net Weight -
0.00kg

Additional Product Information

Commodity Code -
85366990
Country of Origin -
DE
Minimum Order Quantity -
200
RoHs Compliance -
YES
UNSPSC -
25173900

Technical Specification

-
Wago
Diameter connection pin -
- Millimetre
Colour housing -
Grey
Operation temperature -
-60 Degrees celsius
Angle PCB/contact -
90° (upwards vertical)
Connector model -
Free connector
Contact type -
Pin
Housing colour -
Grey
Inflammability class of insulation material acc. with UL94 -
V0
Length pin -
4.5 Millimetre
Material insulation body -
Thermoplastic
Material of contact surface -
Tin
Modular spacing connections -
3.5 Millimetre
Modular spacing contacts -
3.5 Millimetre
Number of plug-in contact rows -
1
Number of poles -
2
Operating temperature -
-60 Degrees celsius
Over voltage category -
III
Pollution degree -
2
Rated current In -
10 Ampere
Rated surge voltage -
2.5 Kilovolt
Rated voltage -
160 Volt
Suitable for PCB thickness -
1.5 Millimetre
Type of banding -
None
Type of connection -
Flexible PCB-connector
Type of electric connection -
Soldering connection
Type of fastening -
Solder
Type of PCB fastening -
Connecting contact

Availability Available to order

Once added to the cart, you can split this pack for a charge of £16.00

£0.48
