6SL33101GF322AA3

SINAMICS G130 Power Module IP20 500-600V 3AC, 50/60 Hz, 215 A Type rating: 132kW 6-pulse design CIM incl. Drive-CLiQ cable without

Manufacturer's No: 6SL3310-1GF32-2AA3     Manufacturer: Siemens
SINAMICS G130 Power Module IP20 500-600V 3AC, 50/60 Hz, 215 A Type rating: 132kW 6-pulse design CIM incl. Drive-CLiQ cable without control module

Availability Available to order

£12,021.78
  • SINAMICS G130 Power Module

    • Type: IP20

    • Voltage: 500-600V 3AC, 50/60 Hz

    • Current: 215 A

    • Power Rating: 132 kW

    • Supply: 6-pulse

    • Design: Without power recovery

    • Includes CIM and Drive-CLiQ cable

    • Excludes control module



Product

Manufacturer Material ID -
6SL3310-1GF32-2AA3
Net Weight -
176.00kg

Additional Product Information

Commodity Code -
85044095
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: 3A999A
RoHs Compliance -
Yes
UNSPSC -
32121704

Technical Specification

Number of HW-interfaces USB -
-
Degree of protection (IP) -
UN
Mains voltage -
- Volt
Mains frequency -
UN
Number of phases output -
UN
Number of phases input -
UN
Max. output frequency -
- Hertz
Max. output at linear load at rated output voltage -
- Kilowatt
Max. output at quadratic load at rated output voltage -
- Kilowatt
Relative symmetric net frequency tolerance -
- Percentage
Max. output voltage -
- Volt
Nominal output current I2N -
- Ampere
Degree of protection (NEMA) -
UN
Number of interfaces PROFINET -
0
Depth -
545 Millimetre
Height -
1533 Millimetre
Number of analogue inputs -
0
Number of analogue outputs -
0
Number of digital inputs -
0
Number of digital outputs -
0
Number of HW-interfaces industrial Ethernet -
0
Number of HW-interfaces other -
3
Number of HW-interfaces parallel -
0
Number of HW-interfaces PROFINET -
0
Number of HW-interfaces RS-232 -
0
Number of HW-interfaces RS-422 -
0
Number of HW-interfaces RS-485 -
0
Number of HW-interfaces serial TTY -
0
Relative symmetric net voltage tolerance -
10 Percentage
Type of converter -
U converter
Width -
326 Millimetre
Commodity Code -
85044095

Availability Available to order

£12,021.78
