6SL33101GH381AA3

SINAMICS G130 Power Module IP00 660-690V 3AC, 50/60 Hz, 810 A Type rating: 800kW 6-pulse design CIM incl. Drive-CLiQ cable without

Manufacturer's No: 6SL3310-1GH38-1AA3     Manufacturer: Siemens
SINAMICS G130 Power Module IP00 660-690V 3AC, 50/60 Hz, 810 A Type rating: 800kW 6-pulse design CIM incl. Drive-CLiQ cable without control module

Availability Available to order

£72,714.21
  • Power Module: SINAMICS G130
  • Voltage: 660-690V AC
  • Frequency: 50/60 Hz
  • Current: 810A
  • Type Rating: 800kW
  • Supply Type: 6-pulse
  • Design: Without power recovery
  • Includes CIM
  • Drive-CLiQ cable included
  • Control module not included


Product

Manufacturer Material ID -
6SL3310-1GH38-1AA3
Net Weight -
530.00kg

Additional Product Information

Commodity Code -
85044088
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: N
RoHs Compliance -
Yes
UNSPSC -
32121705

Technical Specification

Number of HW-interfaces USB -
-
Degree of protection (IP) -
UN
Mains voltage -
- Volt
Mains frequency -
UN
Number of phases output -
UN
Number of phases input -
UN
Max. output frequency -
- Hertz
Max. output at linear load at rated output voltage -
- Kilowatt
Max. output at quadratic load at rated output voltage -
- Kilowatt
Relative symmetric net frequency tolerance -
- Percentage
Max. output voltage -
- Volt
Nominal output current I2N -
- Ampere
Degree of protection (NEMA) -
UN
Number of interfaces PROFINET -
0
Depth -
540 Millimetre
Height -
1510 Millimetre
Number of analogue inputs -
0
Number of analogue outputs -
0
Number of digital inputs -
0
Number of digital outputs -
0
Number of HW-interfaces industrial Ethernet -
0
Number of HW-interfaces other -
3
Number of HW-interfaces parallel -
0
Number of HW-interfaces PROFINET -
0
Number of HW-interfaces RS-232 -
0
Number of HW-interfaces RS-422 -
0
Number of HW-interfaces RS-485 -
0
Number of HW-interfaces serial TTY -
0
Relative symmetric net voltage tolerance -
10 Percentage
Type of converter -
U converter
Width -
909 Millimetre

Availability Available to order

£72,714.21
