191198

YSRW-20-34 Shock absorber

Manufacturer's No: YSRW-20-34     Manufacturer: Festo
YSRW-20-34 Shock absorber

Availability Back Order

£239.38
  • Model: YSRW-20-34 Shock Absorber
  • Self-adjusting with progressive characteristic curve
  • Size: 20, Stroke: 34 mm
  • Cushioning: Self-adjusting, Soft characteristic curve
  • Mounting position: Any
  • Position detection: No
  • Max. impact speed: 3 m/s
  • Reset time at room temperature: 0.3 s
  • Reset time at minimum ambient temperature: 1 s
  • Mode of operation: Pushing, Single-acting

Read more

  • Corrosion resistance class CRC: 2 (Moderate corrosion stress)
  • LABS (PWIS) conformity: VDMA24364-B2-L
  • Ambient temperature range: -10°C to 80°C
  • Cushioning length: 34 mm
  • Max. stop force: 3000 N
  • Max. energy consumption per stroke: 70 J
  • Max. energy consumption per hour: 100000 J
  • Max. residual energy: 0.32 J
  • Reset force: 10 N
  • Min. insertion force: 100 N
  • Product weight: 330 g
  • Load range: Up to 80 kg
  • Type of mounting: Via lock nut
  • RoHS-compliant materials
  • Seals: NBR
  • Housing material: Galvanised steel
  • Piston rod material: High-alloy steel

Accessories



Product

Manufacturer Material ID -
YSRW-20-34
Net Weight -
0.35kg

Additional Product Information

Commodity Code -
84879059
Country of Origin -
DE
UNSPSC -
30102206
Festo

Availability Back Order

£239.38
