252-102

2-Conductor PCB Terminal Block, Push-Button 0.8 mm2 Pin Spacing 3.5 mm 2-Pole Gray

Manufacturer's No: 252-102     Manufacturer: WAGO
2-Conductor PCB Terminal Block, Push-Button 0.8 mm2 Pin Spacing 3.5 mm 2-Pole Gray

Availability Back Order

Once added to the cart, you can split this pack for a charge of £16.00

£0.48
  • 2-conductor female connector with push-button
  • Features PUSH WIRE® technology
  • 0.8 mm Ø pin spacing
  • 2-pole connector for solder pin strip
  • Wire size capacity of 0.50 mm²
  • Color: gray

Accessories

Solder Pin, For PCBs Up To 2 mm Thick

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 243-131
Price £0.04
Back Order


Product

Manufacturer Material ID -
252-102
Net Weight -
0.01kg

Additional Product Information

Commodity Code -
39269097
Country of Origin -
PL
Minimum Order Quantity -
100
UNSPSC -
39121410

Technical Specification

Connectable conductor cross section fine-strand with cable end sleeve -
- Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
- Square millimetre
Connectable conductor cross section multi-wired -
- Square millimetre
Degree of protection (IP), mounted -
UN
Colour housing -
Grey
Operation temperature -
-60 Degrees celsius
Angle PCB/conductor connection -
0°/180° (horizontal)
Connectable conductor cross section solid-core -
0.14 Square millimetre
Connection type conductor -
Plug clamp connection
Connection type PCB -
Soldering connection
Diameter connection pin -
1 Millimetre
Height -
11 Millimetre
Housing colour -
Grey
Inflammability class of insulation material acc. with UL94 -
V0
Length pin -
4.5 Millimetre
Material connection surface -
Tin
Material insulation body -
Thermoplastic
Modular spacing connections -
3.5 Millimetre
Number of electrical connections -
2
Number of levels -
1
Operating temperature -
-60 Degrees celsius
Over voltage category -
III
Pollution degree -
2
Rated current In -
2 Ampere
Rated surge voltage -
4 Kilovolt
Rated voltage -
320 Volt
Type of banding -
None
Type of fastening -
Solder
Type of PCB fastening -
Connecting contact
