252-160

2-Conductor PCB Terminal Block, Push-Button 0.8 mm2 Pin Spacing 3.5 mm 10-Pole Gray

Manufacturer's No: 252-160     Manufacturer: WAGO
2-Conductor PCB Terminal Block, Push-Button 0.8 mm2 Pin Spacing 3.5 mm 10-Pole Gray

Availability Back Order

Once added to the cart, you can split this pack for a charge of £16.00

£2.41
  • 2-conductor female connector with push-button
  • Features PUSH WIRE® technology for easy wiring
  • Pin spacing of 3.5 mm
  • 10-pole connector suitable for solder pin strip
  • Wire diameter of 0.8 mm Ø and 0.50 mm² cross-sectional area
  • Color: gray

Accessories

THT male header, Pin spacing 3.5 mm, 10-pole, black

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 252-910
Price £1.18
Back Order


Product

Manufacturer Material ID -
252-160
Net Weight -
0.01kg

Additional Product Information

Commodity Code -
39269097
Country of Origin -
PL
Minimum Order Quantity -
50
UNSPSC -
39121410

Technical Specification

Connectable conductor cross section fine-strand with cable end sleeve -
- Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
- Square millimetre
Connectable conductor cross section multi-wired -
- Square millimetre
Degree of protection (IP), mounted -
UN
Colour housing -
Grey
Operation temperature -
-60 Degrees celsius
Angle PCB/conductor connection -
0°/180° (horizontal)
Connectable conductor cross section solid-core -
0.14 Square millimetre
Connection type conductor -
Plug clamp connection
Connection type PCB -
Soldering connection
Diameter connection pin -
1 Millimetre
Height -
13.1 Millimetre
Housing colour -
Grey
Inflammability class of insulation material acc. with UL94 -
V0
Length pin -
4.5 Millimetre
Material connection surface -
Tin
Material insulation body -
Thermoplastic
Modular spacing connections -
3.5 Millimetre
Number of electrical connections -
10
Number of levels -
1
Operating temperature -
-60 Degrees celsius
Over voltage category -
III
Pollution degree -
2
Rated current In -
2 Ampere
Rated surge voltage -
4 Kilovolt
Rated voltage -
320 Volt
Type of banding -
None
Type of fastening -
Solder
Type of PCB fastening -
Connecting contact

Availability Back Order

Once added to the cart, you can split this pack for a charge of £16.00

£2.41
