252-305

2-conductor female connector, push-button, PUSH WIRE®, gray

Manufacturer's No: 252-305     Manufacturer: WAGO
2-conductor female connector, push-button, PUSH WIRE®, gray

Availability On Request

Once added to the cart, you can split this pack for a charge of £16.50

POA
  • 2-conductor female connector
  • Push-button with PUSH WIRE® technology
  • Pin spacing of 3.5 mm
  • 5-pole connector for individual solder pins
  • Compatible with KNX systems
  • Wire size of 0.50 mm²
  • Color: gray

Accessories

THT single pin, silver-colored

Once added to the cart, you can split this pack for a charge of £16.50

Product Code - 243-131
Price £0.04
On Request


Product

Manufacturer Material ID -
252-305
Net Weight -
0.75kg

Additional Product Information

Commodity Code -
85369010
Country of Origin -
PL
UNSPSC -
39121410

Technical Specification

Angle PCB/conductor connection -
0°/180° (horizontal)
Connectable conductor cross section solid-core -
0.14 Square millimetre
Connection type conductor -
Plug clamp connection
Connection type PCB -
Soldering connection
Diameter connection pin -
1 Millimetre
Height -
11 Millimetre
Housing colour -
Grey
Inflammability class of insulation material acc. with UL94 -
V0
Material connection surface -
Tin
Material insulation body -
Thermoplastic
Modular spacing connections -
3.5 Millimetre
Number of electrical connections -
5
Number of levels -
1
Operating temperature -
-60 Degrees celsius
Over voltage category -
III
Pollution degree -
2
Rated current In -
2 Ampere
Rated surge voltage -
2.5 Kilovolt
Rated voltage -
160 Volt
Type of banding -
None
Type of fastening -
Solder
Type of PCB fastening -
Connecting contact
