253-106/000-012

2-conductor PCB terminal block, 1.5 mm², Pin spacing 5 mm, orange

Manufacturer's No: 253-106/000-012     Manufacturer: WAGO
2-conductor PCB terminal block, 1.5 mm², Pin spacing 5 mm, orange

Availability On Request

Once added to the cart, you can split this pack for a charge of £16.50

POA
  • 2-conductor PCB terminal block
  • 6-pole with pin spacing of 5 mm
  • Supports wire size up to 1.5 mm²
  • Features PUSH WIRE® connection
  • Color: orange

Accessories

Marking strips, as a DIN A4 sheet, MARKED, white

Once added to the cart, you can split this pack for a charge of £16.50

Product Code - 210-332/500-204
Price POA
On Request


Product

Manufacturer Material ID -
253-106/000-012
Net Weight -
0.88kg

Additional Product Information

Commodity Code -
85365005
Country of Origin -
CH
UNSPSC -
39121410

Technical Specification

Diameter connection pin -
- Millimetre
Connectable conductor cross section fine-strand with cable end sleeve -
- Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
- Square millimetre
Connectable conductor cross section multi-wired -
- Square millimetre
Degree of protection (IP), mounted -
UN
Colour housing -
Orange
Operation temperature -
-60 Degrees celsius
Angle PCB/conductor connection -
Other
Connectable conductor cross section solid-core -
0.5 Square millimetre
Connection type conductor -
Plug clamp connection
Connection type PCB -
Soldering connection
Height -
13 Millimetre
Housing colour -
Orange
Inflammability class of insulation material acc. with UL94 -
V0
Length pin -
3.6 Millimetre
Material connection surface -
Tin
Material insulation body -
Thermoplastic
Modular spacing connections -
5 Millimetre
Number of electrical connections -
6
Number of levels -
1
Operating temperature -
-60 Degrees celsius
Over voltage category -
III
Pollution degree -
2
Rated current In -
17.5 Ampere
Rated surge voltage -
4 Kilovolt
Rated voltage -
320 Volt
Type of banding -
None
Type of fastening -
Solder
Type of PCB fastening -
Connecting contact

Availability On Request

Once added to the cart, you can split this pack for a charge of £16.50

POA
