2624-1504/000-004

PCB terminal block, 4 mm, Pin spacing 11.5 mm, 4-pole, Push-in CAGE CLAMP, 4, 00 mm, black

Manufacturer's No: 2624-1504/000-004     Manufacturer: WAGO
PCB terminal block, 4 mm, Pin spacing 11.5 mm, 4-pole, Push-in CAGE CLAMP, 4, 00 mm, black

Availability Back Order

Once added to the cart, you can split this pack for a charge of £16.00

£2.54
  • PCB terminal block
  • 4-pole
  • Pin spacing: 11.5 mm
  • Wire size: 4.00 mm
  • Push-in CAGE CLAMP
  • Color: Black

Ferrule, Sleeve For 0.5 mm / Awg 22 Insulated White

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-241
Price £0.09
Back Order

Ferrule, Sleeve For 0.75 mm / Awg 20 Insulated Gray

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-242
Price £0.09
Back Order

Ferrule, Sleeve For 0.75 mm / Awg 20 Insulated Gray

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-262
Price £0.09
Back Order

Ferrule, Sleeve For 1 mm / Awg 18 Insulated Red

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-263
Price £0.09
Back Order

Ferrule, Sleeve For 1.5 mm / Awg 16 Insulated Black

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-244
Price £0.09
Back Order

Ferrule, Sleeve For 1.5 mm / Awg 16 Insulated Black

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-264
Price £0.09
Back Order

Ferrule, Sleeve For 2.5 mm / Awg 14 Insulated Blue

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-246
Price £0.09
Back Order

Ferrule, Sleeve For 2.5 mm / Awg 14 Insulated Blue

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-266
Price £0.09
Back Order

Ferrule, Sleeve For 2.5 mm / Awg 14 Uninsulated

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-106
Price £0.02
Back Order


Product

Manufacturer Material ID -
2624-1504/000-004
Net Weight -
0.50kg

Additional Product Information

Commodity Code -
85364900
UNSPSC -
39121402

Technical Specification

Diameter connection pin -
- Millimetre
Degree of protection (IP), mounted -
UN
Colour housing -
Black
Operation temperature -
-60 Degrees celsius
Height -
15.4 Millimetre
Housing colour -
Black
Rated voltage -
1000 Volt
Operating temperature -
-60 Degrees celsius
Type of fastening -
Solder
Inflammability class of insulation material acc. with UL94 -
V0
Number of levels -
1
Rated surge voltage -
8 Kilovolt
Over voltage category -
III
Pollution degree -
2
Connection type conductor -
Spring clamp connection
Connection type PCB -
Soldering connection
Length pin -
4 Millimetre
Material connection surface -
Tin
Modular spacing connections -
11.5 Millimetre
Type of banding -
None
Connectable conductor cross section solid-core -
0.2 Square millimetre
Connectable conductor cross section fine-strand with cable end sleeve -
0.25 Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
0.2 Square millimetre
Connectable conductor cross section multi-wired -
0.2 Square millimetre
Material insulation body -
Thermoplastic
Angle PCB/conductor connection -
0°/180° (horizontal)
Type of PCB fastening -
Connecting contact
Rated current In -
41 Ampere
Number of electrical connections -
4
