50126547

The Single beam safety device transmitter from . Type: 4, IEC/EN 61496; Operating range: 5 ... 70 m; Operating range limit: 5 ...

Manufacturer's No: SLS46C-70.K48     Manufacturer: Leuze
The Single beam safety device transmitter from . Type: 4, IEC/EN 61496; Operating range: 5 ... 70 m; Operating range limit: 5 ... 80 m; Light source: LED, Red; Response time: 2,5 ms; Supply voltage:

Availability Back Order

£141.00
  • Activation input: Type 4, IEC/EN 61496
  • SIL: 3, IEC 61508 (in combination with MSI-TRMB safety relay)
  • Performance Level (PL): e, EN ISO 13849-1:2008
  • Category: 4, EN ISO 13849:2008
  • Operating range: 5m to 70m
  • Operating range limit: 5m to 80m
  • Light source: Red LED
  • Supply voltage: 24V DC, -20% to +20%
  • Response time: 2.5 ms
  • Connection: 2,000mm PUR cable

Read more

  • Design: Cubic
  • Dimensions: 20.5mm x 76.3mm x 44mm

Accessories

Others



Product

Manufacturer Material ID -
SLS46C-70.K48
Net Weight -
0.13kg

Additional Product Information

Commodity Code -
85365019
Country of Origin -
DE
UNSPSC -
39121528

Technical Specification

Diameter -
- Millimetre
Number of semiconductor outputs with signalling function -
-
Number of protected semiconductor outputs -
-
Type of interface for safety communication -
UN
Type of switching output -
UN
Scope of delivery of the one-way system -
UN
Max. output current at protected output -
- Milliampere
Switching voltage of OSSD at state "high" -
- Volt
Time of reaction -
25 Millisecond
Thumbnail of product picture -
Ambient temperature -
-30 Degrees celsius
Construction type housing -
Cubic
Explosion safety category for dust -
None
Explosion safety category for gas -
None
Height -
76.3 Millimetre
Length -
44 Millimetre
Number of contact energized outputs with signalling function -
0
Number of protected contact energized outputs -
0
Operation agent-safety class -
Safety class 3
Reaction time -
2.5 Millisecond
Transmission range of the safety field -
70 Metre
Type of electric connection -
Cable axial
Type of safety acc. IEC 61496-1 -
4
Voltage type -
DC
Wavelength of the sensor -
630 Nanometre
Width -
20.5 Millimetre
Leuze

Availability Back Order

£141.00
