MasterEncoder – model series connection master for up to 3 subscribers up to 4 encoder inputs 30 mm

Manufacturer's No: PSEN sc ME 5.5 08-17     Manufacturer: Pilz
MasterEncoder – model series connection master for up to 3 subscribers up to 4 encoder inputs 30 mm

Availability Available to order

£4,522.47
  • Model: MasterEncoder
  • Series connection master for up to 3 subscribers
  • Encoder inputs: up to 4
  • Detection capability: 30 mm, 40 mm, 50 mm, 70 mm, 150 mm
  • Safety features: muting, partial muting, override, EDM, restart applications (EN ISO 61496-3 compliant)
  • Vertical application support
  • Reference markers for precise positioning
  • Measured data output via UDP
  • Temperature range: -10°C to +50°C
  • Safety zone: 5.5 meters

Read more

  • Connection options: expanded I/O
  • 3 safety zones and 3 warning zones can run in parallel
  • 70 configurable zone sets
  • Features fast replacement and exchangeable memory block
  • ROS and C++ interface available
  • Window replacement option

Mandatory additional product

Accessories



Product

Manufacturer Material ID -
PSEN sc ME 5.5 08-17
Net Weight -
1.53kg

Additional Product Information

Commodity Code -
90314990
Country of Origin -
IT
UNSPSC -
43201542

Technical Specification

Thumbnail of product picture -
Medien_800/Pictures_800/6D000034_800.jpg
Ambient temperature -
-10 Degrees celsius
Height of sensor -
152 Millimetre
Length of sensor -
112.5 Millimetre
Number of protected semiconductor outputs -
5
Reaction time -
62 Millisecond
Type of safety acc. IEC 61496-1 -
3
Voltage type -
DC
Width sensor -
102 Millimetre
